To develop C programs for the TI-84+ using z88dk, you need to follow a series of steps to set up your environment, write your program, and compile it for the calculator. Here is a step-by-step guide to help you through the process:

Step 1: Install z88dk

1. Download z88dk:

   • Visit the official website: z88dk to download the appropriate version for your operating system.

   • Alternatively, you can find it in package managers like apt on Linux.

   • For Windows, you can use the z88dk Windows installer or download the precompiled binaries.

2. Install z88dk:

   • Follow the installation instructions for your system. On Windows, ensure that the bin folder (containing zcc and other tools) is added to your system’s PATH variable.

   • For Linux, extract the package and add the path to your .bashrc or .zshrc file, depending on your shell.

Step 2: Set Up Your TI-84+ Development Environment

1. TI-84+ SDK:

   • The TI-84+ does not natively support C, so we will be using TI-83/84 Plus SDK, which supports assembly and C programs.

   • You will need to ensure that your z88dk installation is compatible with the TI-84+ (or TI-83) calculator models.

2. Install Necessary Dependencies:

   • Ensure you have any required dependencies for the z88dk environment, including tools like make (on Linux) or MinGW (on Windows).

Step 3: Set Up the Project Directory

1. Create a project directory:

   • Inside your desired folder, create a directory for your project. For example, name it ti84_project.



   Copy Below

   mkdir ti84_project
cd ti84_project



2. Create a C Source File:

   • Inside the ti84_project folder, create a new C source file using any text editor of your choice. For example, name it main.c:

     Copy Below

     #include <ti84plus.h>

     int main(void) {
     // Initialize the calculator
     ClrHome();
     Print(“Hello, TI-84+!”);

     while (1) {
     // Loop forever, doing nothing
     }

     return 0;
     }



Step 4: Writing C Code

• Access TI-84+ Functions: To use the TI-84+ hardware functions, you will need to link against the TI-83/84+ SDK, which provides the functions like ClrHome(), Print(), etc.

• You can access the entire TI-84+ SDK and its capabilities via the ti84plus.h header.

Step 5: Compiling the Program

1. Compiling with z88dk:

   • In your project directory, run the following command to compile your C source file into an assembly file that is compatible with the TI-84+:



   Copy Below

   zcc +ti84 -clib=ti84plus -lm main.c -o ti84_program



   Explanation:

   • +ti84: This flag tells z88dk to target the TI-84+ hardware.

   • -clib=ti84plus: Links the standard library for TI-84+.

   • -lm: Links math functions.

   • -o ti84_program: Specifies the output file’s name (e.g., ti84_program).

2. Convert to a TI-84+ format:

   • The generated file might need to be converted into a format suitable for uploading to the calculator.

   • Run the following command to generate the final .8xk file (TI-84+ executable):



   Copy Below

   python3 -m ti84plus tios_program



Step 6: Transfer the Program to the TI-84+

1. Use TI Connect Software:

   • Download and install TI Connect CE (for TI-84+) from the official Texas Instruments website.

   • Connect your TI-84+ to your computer via USB.

2. Transfer the Program:

   • Open TI Connect CE and use the Send button to transfer the .8xk file to your TI-84+.

Step 7: Run the Program on the TI-84+

1. Launch the Program:

   • On your TI-84+, press the PRGM button, select your program from the list, and press ENTER.

   • Your program should now execute, and you should see “Hello, TI-84+” displayed on the screen.

Step 8: Debugging and Troubleshooting

• Compiler Errors: If there are errors during compilation, carefully read the error message and check your code. You may have forgotten to include the correct header files or used unsupported functions.

• Runtime Errors: If the program crashes or behaves unexpectedly, debug by adding Print() statements or other diagnostics to track what is happening.

Additional Notes:

• Documentation: Always consult the TI-83/84+ SDK documentation and the z88dk manual for more advanced usage.

• Testing: Before finalizing your project, run several test cases and make sure the program behaves correctly on the calculator.

This should give you a step-by-step process to develop and deploy C programs for the TI-84+ calculator using z88dk.
